RG11 Details



RG11 Standard Specification :
1.63Copper+7.11mmFoam PE+AL Foil+90%Braid+10.30mm PVC
Options:
Inner conductor Material CCS/COPPER/CCA
Diameter 1.63mm
Dielectric Material Foam PE
Diameter 7.11mm
Shield 1st shield Al foil/copper foil
2nd shield 96/112/128/144/168Al-Mg /CCAM/Copper/TC
Tri- shield Al foil/copper foil
Qual-shield Al-Mg /CCAM/Copper/TC
Jacket Material PVC or PE /PVC Degree: 65,68,70,75 /white or black
Diameter 10.3mm
Packing 305m 500m with wooden drum, plastic spool, inner color box, pulling box, outer cartons etc.
Remark Other specs available according to clients requests.
