Conductor:
Sliver-tinnd OFC
Bare OFC
CCA10A/H
CCA 15A/H
PVC Insulation:
Solid
Transparent
Big Bright
Sand Finish Non-bright
| Product No. | Type | Conductor | ODmm |
| HB 101 | 2×0.2mm² | CU/CCA | 1.6×3.2mm |
| HB 102 | 2×0.25mm² | CU/CCA | 1.8×3.6mm |
| HB 103 | 2×0.35mm²/td> | CU/CCA | 2.0×4.0mm |
| HB 104 | 2×0.5mm² | CU/CCA | 2.2×4.4mm |
| HB 105 | 2×0.75mm² | CU/CCA | 2.5×5.0mm |
| HB 106 | 2×1.0mm² | CU/CCA | 3.0×6.0mm |
| HB 107 | 2×1.5mm² | CU/CCA | 3.5×7.0mm |
| HB 108 | 2×2.0mm² | CU/CCA | 3.8×7.5mm |
| HB 109 | 2×2.5mm² | CU/CCA | 4.0×8.0mm |
| HB 110 | 2×3.0mm² | CU/CCA | 4.5×7.0mm |
| HB 111 | 2×4.0mm² | CU/CCA | 5.0×10mm |
| HB 112 | 2×5.0mm² | CU/CCA | 5.5×11mm |
| HB 113 | 2×6.0mm² | CU/CCA | 6.0×12mm |
| Product No. | Type | Conductor | ODmm |
| HB 201 | 26AWG | CU/CCA/CCS | 1.7×3.4mm |
| HB 202 | 24AWG | CU/CCA/CCS | 1.8×3.6mm |
| HB 202 | 22AWG | CU/CCA/CCS | 2.0×4.0mm |
| HB 204 | 20AWG | CU/CCA/CCS | 2.2×4.4mm |
| HB 205 | 18AWG | CU/CCA/CCS | 2.5×5.0mm |
| HB 206 | 16AWG | CU/CCA/CCS | 3.0×6.0mm |
| HB 207 | 14AWG | CU/CCA/CCS | 3.5×7.0mm |
| HB 208 | 12AWG | CU/CCA/CCS | 4.0×8.0mm |
| HB 209 | 10AWG | CU/CCA/CCS | 5.5×10.0mm |
